SRT DL3020 Waterproof Standard Size Digital Servo
zoom_out_map
chevron_left chevron_right

SRT DL3020 Waterproof Standard Size Digital Servo

SRT DL3020 Waterproof Standard Size Digital Servo

€24.90
Free for 830 points Free for 830 points
check Avaible
>Earn 5 points/€0.15 Earn 5 points/€0.15 (Each €5.00 spent = 1 point, 1 point = €0.03 discount)
Your cart will total 5 points that can be converted into a voucher of €0.15.
Secure payments with credit card and PayPal
Worldwide shipments with express courier
Money Back Guarantee

Description

SRT DL3020 Waterproof Standard Size Digital Servo

The latest generation of SRT  servos provides you with the performance you need for any scale vehicle\ Air Plane\Boat\Robot application. are standard size servos.

Features:
  • Ideal for 1/8 & 1/10 on road, GT and 1/8 off road scale applications
  • Superior Holding Torque
  • Incredible efficiency and low power consumption
  • Standard dimension make it perfect for vehicles that can benefit from a high quality servo
  • Waterproof
  • 25T output shaft
  • 2 μsec Dead Band
  • 1-Year Limited Warranty
Specifications:
Type: Digital
Bearing: Dual
Motor Type: DC
Gear Type: Metal
Gear Material: Brass / Alu
Control system: Pulse width control
Working frequence: 1520μs / 330hz
Operating voltage: dc 4.8-6.0v
Operating temperature range: -10 to + 60 degree
Operating speed (4.8V): 0.13 sec/60 degrees at no load
Operating speed (6.0V): 0.11 sec/60 degrees at no load
Operating speed (7.4V):
Stall torque (4.8V): 18.0kg.cm (347.2 oz/in)
Stall torque (6.0V): 20.0kg.cm (416.6 oz/in)
Stall torque (7.4V):
Potentiometer drive: Direct drive
Dimensions: 40.7 x 20.5 x 39.5 mm
Weight: 56.0g
Connector wire length: jr 300 mm

Data sheet

DL3020
0.20 kg
